主要用途
適用各種根莖類、塊類、果實類藥材的長片、直片切制。
Main uses
suitable to cut different roots、blocks、seeds into pieces.
主要特點
物料由氣缸壓緊，通過調整刀片與刀架間隙獲得不同規格片厚度。壓緊力可調整，刀架前后均裝有自動噴水機構，避免藥物在切制過程中粘附于刀刃影 響藥片刨切質量，刀片兩端在往、復過程中均可切制。本機具有結構合理，便于使用操作、耗能低、刀片易裝卸、刨片厚度品種多等優點，符合GMP要求。
Main technical characteristics
The herb is pressed by the cylinder. The different herb sizes can be achieved by adjusting the gap between the knife and the knife holder. There are automatically spraying faucets on both sides of the knife holder, thus it can prevent the herb sticking to the knife. The knife can cut reciprocally. The machine is easy to operate and could meet the requirements of GMP.
主要技術參數 Main technical parameter
型號
Type |
生產能力
Capacity
(kg/h) |
切片厚度
cut herb
thickness
(mm) |
藥口尺寸
herb inlet
door size
(mm) |
電機功率
motor
(KW) |
外形尺寸
dimension
(mm) |
整機重量
weight
(kg) |
|
QWB200 |
100-800 |
1-6 |
200X200 |
3 |
2120X7000X1760 |
550 |
